Replacement LED Strip for Jacuzzi J-400 Waterfall
The Jacuzzi 6560-183 LED strip is designed to illuminate the waterfall on Jacuzzi J-400 Series hot tubs. It replaces the original LED strip on compatible models, particularly when the waterfall lighting stops working.
This replacement part snaps into place beneath the waterfall. It measures 290 mm in length and comes with a 4.30 m cable featuring a mini-DIN connector.
It also replaces the discontinued Jacuzzi part number 20096-001. However, checking the connector before ordering is essential, as the two versions use different connector types.
| Brand | Jacuzzi |
| Manufacturer Part Number | 6560-183 |
| Previous Part Number | 20096-001 |
| Product Type | LED strip for hot tub waterfall |
| Compatible Series | Jacuzzi J-400 |
| Length | 290 mm |
| Height | 14 mm |
| Cable Length | 4.30 m |
| Connector | Mini-DIN |
| Mounting | Snap-in |
Which Jacuzzi Hot Tub Models Are Compatible?
This LED strip is designed for the following Jacuzzi J-400 Series hot tubs:
- Jacuzzi J-465: 2006 to 2015.
- Jacuzzi J-470: 2006 to 2015.
- Jacuzzi J-480: 2006 to 2015.
- Jacuzzi J-415: 2012 to 2015.
- Jacuzzi J-425: 2012 to 2015.
- Jacuzzi J-495: 2012 to 2015.
Compatibility depends on the hot tub model, year of manufacture, and existing electrical connection.
Our recommendation: Before ordering, identify your hot tub model and compare the connector on your existing LED strip with the one used on part number 6560-183.
Replacing Jacuzzi Part Number 20096-001
The 6560-183 LED strip replaces the discontinued Jacuzzi 20096-001. However, checking the connector is essential because the two versions use different connections:
- Jacuzzi 6560-183: Mini-DIN connector.
- Jacuzzi 20096-001: IDC flat ribbon cable connector.
For hot tubs manufactured between 2006 and 2012, a mini-DIN to IDC adapter is required to connect the new LED strip to the existing wiring.
Installation and Checks Before Replacement
The 6560-183 LED strip features a snap-in mounting system beneath the hot tub waterfall. Its 4.30 m cable connects to the mini-DIN socket found on compatible installations.
Before replacing your waterfall lighting, follow these steps to make sure you order the correct part:
- Identify the exact model and year of manufacture of your hot tub.
- Check the part number on your existing LED strip, if still visible.
- Compare the dimensions of your existing LED strip with those of the replacement.
- Check the connector type and determine whether an adapter is needed.
Frequently Asked Questions
What is the Jacuzzi 6560-183 LED strip used for?
This LED strip provides backlighting for the waterfall on select Jacuzzi J-400 Series hot tubs. It is designed to replace the existing waterfall lighting, provided the hot tub model, year of manufacture, and electrical connection are compatible.
Can it replace an older Jacuzzi 20096-001 LED strip?
Yes, part number 6560-183 replaces the older 20096-001. However, the new version uses a mini-DIN connector, while the original features an IDC flat ribbon cable connector.
Do I need an adapter to install this LED strip?
A mini-DIN to IDC adapter is required for affected hot tubs manufactured between 2006 and 2012. Check your existing connector before ordering, as it has not been confirmed whether the adapter is included with the LED strip.
What are the dimensions of the Jacuzzi 6560-183 LED strip?
This LED strip measures 290 mm in length and 14 mm in height. It comes with a 4.30 m cable and a mini-DIN connector. Compare these specifications with your existing part before ordering.
How is the LED strip mounted beneath the waterfall?
The LED strip is designed to snap into place beneath the waterfall. Before replacing it, check the dimensions of your existing LED strip and the connector type used by your hot tub.
