ESPA

Ref : A-000000-09120

ESPA WIPER0 90M Spa/Pool Pump – 1 HP (0.85 kW) – Single-speed

Name: ESPA WIPER0 90M Spa/Pool Pump – 1 HP (0.85 kW) – Single-speed
Brand: ESPA
SKU: A-000000-09120
Price: 375 EUR
Availability: InStock

WIPER0 90M Circulation Pump
Single speed
Power 1HP equivalent to 0.85 Kw

375,00 €

In Stock

Only 2 items left in stock

Worldwide delivery
Pay in 4x free of charge with Read more
100% compatible parts
2-year warranty (1 year for professionals)

Technical characteristics

WIPER0 90M Circulation Pump - ESPA
Single speed
Power 1 HP equivalent to 0.85 Kw
ESPA Reference: WIPER0 90M

FEATURES:

Pump body and removable foot in fiberglass-reinforced polypropylene
24/24h operation
50mm suction and discharge diameter
Polypropylene impeller
Stainless steel motor shaft. AISI 420
Equipped with a capacitor (Allows pump ignition/triggering)
Compatible with saltwater (7g/l)
Suitable for spas and pools

Model	Hmax (m)	Power kW	Power HP	Weight (kg)
WIPER0 M 4P	3	0.13	1/15 HP	5
WIPER0 50M 4P	10.5	0.5	0.5 HP	5.7
WIPER0 70M 4P	11.5	0.65	0.7 HP	6
WIPER0 90M 4P	12.5	0.85	1 HP	6.8

Technical Diagrams

Dimensions WIPER0 M 4P

Pipe Connections

Supplied with 50mm threaded outlet fittings
You can also reuse your old pipe fittings if they are still functional.
If your piping differs, check our range of Pump Unions and Fittings to find the fitting that matches your piping

Electrical Connection

The pump is supplied without a connection cable or plug. You can keep your old cable to connect this new pump. If your plug is no longer usable, you can opt for new plugs in our Spa Cables and Plugs section

Here are the most commonly used Plugs in the Spa industry:


AMP Plug	J&J Plug (PIN position varies depending on the device)

Equivalent products

Related categories

Circulation Pumps

Massage Pumps

Spas Blower

Pumps Pressure Switches

Pump Union Connectors

Fixing plates
