Spare parts (page 46)

For series 780 (Camdem, Certa, Chelsee, Hamilton)
6-pin connector

Manufacturer reference: 860204
Built-in WiFi module

Embedded hole diameter: 65mm
Front diameter: 86mm
Water inlet: 3/4” fitting (27mm)
Air inlet: 3/8” fitting (14.5mm)
Ring and gasket included

Reference: E-170
Material: ABS

Waterway Reference : 236-7157S
Jet face diameter : 190mm
Socket installation hole diameter : 140mm

Reference LVJ: L-2313S
Stainless Steel Front Panel
LED not included


Canadian Spas Reference: KK-10047
Length: 56mm
Front diameter: 51mm
Clip diameter: 24 mm
Outer diameter of water inlet: 15 mm
Jet body length: 45 mm
Sleeve not included

Reference Wellis: ACM0622
Only the stainless steel chamber

Model: K-30 or TSC30 - 1 Pump

LITE Keyboard Sticker
2-button model

Length: 95 mm
Front Diameter (Stainless Steel): 76 mm
Socket Fixing Diameter: 45 mm
External Diameter of Water Inlet: 17 mm
Socket not included

• Reversible: heats and cools your spa + automatic defrosting
• Up to 75% savings vs electric heater
• Built-in Wi-Fi, simplified remote control
• Compact, quiet, Plug & Play installation
• Compatible with acrylic spas and Nordic baths

Compatible with: J-445, J-435, J-495, J-480, J-470, J-425, J-415
Reference: 6600-379

Front Diameter: 100mm
Length: 113mm
Thread Diameter: 41mm
Outer Diameter Water Inlet: 22mm
Socket not included

Front Diameter: 100mm
Length: 113mm
Thread Diameter: 41mm
Outer Diameter Water Inlet: 22mm
Socket not included

Model: TSC-42 or K-42
Replaces reference: 01560-1005


1" (50mm) Luxury Elegant Series Jet
Stainless Steel Face
Directional Jet (non-adjustable): L-1008S

Hydroquip Spa Heater C2550-0309ET
Power: 5.5Kw
For spas using a Hydroquip CS-9400EX control system

Delivered without connector

Manufacturer reference: 78191

Compatible with Sundance® 880 series spas after 2009.

Front face material: Brushed stainless steel.
Body material: Black ABS.
Mounting type: Snap-in.

A support that is installed at the bottom of the skimmer and accepts all filters with a 1.5" SAE thread (48mm).
Screw thread: 2" (60mm)

100 m Coil – Blue Clear Flexible Hose for Spa 9 x 14 mm – Transparent PVC
Outer Diameter: 14 mm
Inner Diameter: 9 mm

Compatible with: Caldera Spas, Cantabria - 2018-C / Florence - 2018-C / Geneva - 2018-C / Niagara - 2018-C / Tahitian - 2018-C
Reference: 78190

Power : 1HP - 800W
Outputs : 2" (62mm)
Typology : Single speed
Manufacturer's reference : 1713-WC
Replaces identically such pump Koller 1713-WTC in 1HP - 2" fittings

Canadian Spa Reference: KK-10051
Length: 115 mm
Front Diameter: 89mm
Clip Diameter: 36 mm
Outer Diameter of Water Inlet: 22 mm
Jet Body Length: 101 mm

The Complete Keyboard includes references 73225 + 71510 / 71509
Compatible with HotSpring® spas

Spa pump Model PISCIS3 50M 0.5HP by ESPA
Single speed
Power 0.5 HP equivalent to 0.37 Kw
Replaces the WIPER0 pump PP04200

Manufacturer reference: G50-2NN-S
Suitable for 8 to 15 jets

Front Diameter: 100mm
Length: 113mm
Screw Thread Diameter: 41mm
Outer Diameter Water Inlet: 22mm
Socket not included
